HPE MSA 2060 Storage

An affordable, flash-ready hybrid storage system that provides cost-effective application acceleration.

Highly scalable and excellent at handling compute intensive workloads, MSA 2060 storage arrays are ideal for small businesses who require an entry-price system that still packs a serious punch.



A flash-ready hybrid storage system, the HPE MSA 2060 is built and designed to provide simple, cost-effective application acceleration for small and remote office deployments. It combines affordability with simplicity, flexibility and a bevvy of advanced features not often found in an entry-priced array.

You are able to start small and scale as required, with any combination of SSDS, high performance Enterprise SAS HDDs, or lower-cost Midline SAS HDDs. Excelling with even the most demanding workloads. the new MSA 2060 is up to 45% faster than the previous generation and can provide up to 325,000 IOPS.

The HPE MSA 2060 SAN Storage range offers a wide range of new features, including:

  • The new 6th generation MSA storage architecture delivers a modernised HW platform with additional resources for features like Tiering 2.0, a new RAID protection scheme (MSA-DP+), brand new task-optimised web interface and super optimised data management through a newly introduced RESTful interface.
  • Enhanced array performance that delivers more IOPS, bandwidth and backend connectivity. Experience an up to 45% increase on IOPS and up to 70% improvement on sequential throughput over the previous generation.
  • Able to provide over 325,000 IOPS for cost-effective application acceleration for small/medium sized businesses.
  • New HPE MSA 18TB SAS 7.2K LFF HDD available in single drive and six-pack bundles options.

MSA-DP+ RAID-Based Data Protection

MSA-DP+ is a RAID-based data protection level that has been newly introduced with 6th Gen MSA Storage systems. It maximises flexibility and delivers built-in spare capacity. Performance is optimised with the elimination of idle spares. MSA-DP+ enables for quick rebuilds, large storage pools and easy expansion.

Enhanced Simplicity

Increased simplicity with a new disk group type (MSA-DP+) that boosts availability, significantly reduces RAID rebuild times, enhances performance, simplifies setup and provides a more granular expansion of disk pools.

Better Performance

Performance is significantly improved (up to 45% faster) on the prior generation with more IOPs, bandwidth and backend connectivity. Experience an up to 70% improvement on sequential throughput.

Standard Features

Capacity

  • 92.16TB SFF / 192TB LFF

Maximum total HDDs per array

  • 240 SFF / 120LFF

Maximum total SSDs per array

  • 240 SFF / 120LFF

LFF/SFF array/enclosure mixing

  • Supported

Drive enclosure interface type

  • 12Gb SAS

Max Read cache per array

  • 8TB

RAID Levels supported

  • RAID 0*,1, 5, 6, 10, MSA-DP+

Form Factor

  • 2U

Minimum dimensions ( H x W x D)

  • 8.9 x 44.5 x 50.8 cm

Weight

  • LFF Enclosure: 32 kg; SFF Enclosure: 30 kg

Technical Specifications
Array
Access Type Block
Form Factor 2U, Small Form Factor (SFF) or Large Form Factor (LFF)
Number of controllers per array 2
Number of host ports per array 8
FC host connectivity 16Gb
SCSI host connectivity 10Gb
SAS host connectivity 12Gb
Cache, per array
Max Read cache per array 8TB
Data (read/write) cache + system memory per array 24GB
Pool Capacity Two Pools with 1 PBeach
RAID Levels supported RAID 0*,1, 5, 6, 10, MSA-DP+
Enclosures
Expansion Drive Enclosures 0-9 enclosures
LFF/SFF array/enclosure mixing Supported
Maximum number of drives per array enclosure 24 SFF/12 LFF
Maximum number of drives per drive enclosure 24 SFF/12 LFF
Drive enclosure interface type 12Gb SAS
Drives
Maximum total HDDs per array 240 SFF / 120LFF
Maximum total SSDs per array 240 SFF / 120LFF
Max raw capacity per array enclosure 92.16TB SFF / 192TB LFF
Max raw capacity per drive enclosure 92.16TB SFF / 192TB LFF
Max raw capacity per array 921.6TB SFF / 1.92PB LFF
Drive Capacities
SFF SSDs 960GB, 1.92TB, 3.84TB
LFF SSD 1.92TB
SFF HDDs 15K: 900GB; 10K: 600GB, 1.2TB, 1.8TB, 2.4TB
LFF HDDs 7.2K: 6TB, 8TB, 10TB, 12TB,14TB,16TB
Self-Encrypting SSDs SFF: 960GB, 1.92TB; LFF: 1.92TB
Self-Encrypting HDDs SFF: 900GB, 2.4TB; LFF: 12TB
Software Features
Thin Technologies Thin Provisioning, Space Reclamation, Thin Rebuild
Tiering Performance Tier, Standard Tier, Archive Tier
Replication Snapshots (512), Volume Copy, Remote Snaps
Quality of Service Virtual Tier Affinity
Additional Features
Maximum number of volumes 512
Maximum number of snapshots 512
Maximum number of hosts 512
Maximum number of initiators 1024
Customer self-installable Yes
Customer self-repairable Yes
Customer self-upgradeable Yes
Health Check analytics Yes
Energy Star Certified Yes

Extensive Testing

Before leaving our build and configuration facility, all of our server and storage solutions undergo an extensive 48 hour testing procedure. This, along with OEM HPE components we use ensure all of our server and storage solutions meet the strictest quality guidelines demanded from us.


Customization Service

Our main objective is to offer great value, high quality server and storage solutions, we understand that every company has different requirements and as such are able to offer a complete customization service to provide server and storage solutions that meet your individual needs.
